“aira” Offers FEP / PFA Lined Diaphragm Valve are generally used for pressure, temperature, flow & level control of extremely Corrosive, Hazardous, pure Liquid, Vapours and Gas Media in the Chemical, Pharmaceutical and Other Industrial applications. The lining is done in – house.
| Specification | Details |
|---|---|
| Design & Manufacturer | API 600 / BS 1873 |
| Valve Face To Face Dimension | DIN 3202 |
| Inspection & Testing | API 598 / BS EN 12266 PART – I |
| Leakage Class | Class VI |
| End Connection | Flanged End |
| Valve Rating | Flanged 150# |
| Spark Test | 15 Kv DC to 40 Kv DC |
| Certification | Design CE Approved, SIL3 Approved, IBR Approved |
| Shutoff Rating | VI Class |
| Stem Material | CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M |
| Size Range | 1/2” To 8” (15MM To 200MM) |
| Temperature Range | -50°C To 300°C For Soft Seated Valves. Contact Works For Special Requirement |
| Pressure Class | PN 6 |
| Media | Chemical |
| Body Material | CAST IRON (CI), DUCTILE IRON (DI), S.G IRON (SGI), WCB, CF8, CF8M, CF3M, SS 304L, DUPLEX, HAST ALLOY, MONEL |
| Bonnet Material | CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M |
| Flange Drilling | ASME B 16.5 Class 150# |
| Face To Face | ASME B 16.10 |
| Fugitive Emissions | Yes |
| Disc Material | CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M |
